1.Higher sensitivity:
The accuracy of the sensor signal processing circuit has been improved. The
maximum processing resolution has been developed to be 0.1㎛.
Minute displacement at the bottom dead center can be detected.
2.Displacement check with digital display and micron-indicator:
The displacement is displayed simultaneously both with the digital display
having high reading accuracy and the micron-indicator easy to check the
condition. This enables an easy-check of the operation conditions of the detector.
3.Displayed gap for sensor installation:
The distance between the sensor head and a target is displayed at the time of
installing the sensor. Without the use of the gap gauge, the sensor can be installed
accurately.
4.Flexible adjustment of the sensor cable length:
The cable compensation function enables fine adjustment of the cable length on
site. The cable length can be freely set for each channel.
5.Developed detection timing:
The external timing is produced from 2 inputs and the internal timing is from
each channel. If the internal angle timing is used, the equivalent detection with
the external timing can be achieved without an external cam.
6.Effective timing test:
The timing test can detect out of control conditions such as unusal installation of
the sensor and improper operation of the external cam.
7.ES : add 2 channels for detecting error carrying. Could choose to detect missing
material or material jammed.
8.Mean value and absolute value can be selected.
9.This product can be chosen to set up in effective or ineffective.
10.SP: Displays when speed is abnormal and machine stops. Other reasons: upper
or lower iron blocks drop out suddenly.
11.Option available for detection in advance: using soft material (copper) under
0.5mm, could detect abnormal before slug pressed.
